General & Physical Tests
Showing 1–24 of 29 results
-
General & Physical Tests
150 Degrees Temperature Humidity Test Machine
A humidity test chamber, also known as an environmental chamber, is a specialized piece of equipment used to test the effects of humidity on plastic materials and products. These chambers are designed to simulate various humidity conditions, including high humidity, low humidity, and rapid changes in humidity, in order to evaluate the performance and durability of plastic materials and products under real-world conditions.
Humidity test chambers are commonly used in a variety of industries, including automotive, electronics, medical, and packaging. The plastic materials and products subjected to humidity testing can range from electronic components and medical devices to automotive parts and packaging materials.
The chamber typically consists of a temperature and humidity-controlled test chamber with a test specimen holder, a humidity generator, a temperature controller, and a data acquisition system. The test specimen is placed in the chamber, and the humidity and temperature conditions are set according to the specific test requirements. The test specimen is then subjected to the specified conditions for a specific period of time, and the results are recorded and analyzed.
Humidity test chambers are an essential tool for ensuring the quality and reliability of plastic materials and products. They allow manufacturers to evaluate the effects of humidity on their products and make necessary adjustments to improve performance and durability. They are also used to validate the performance of the product under different humidity conditions, which is important for products that will be used in different climates or environments.
SKU: n/a -
-
Electrical & Electronic, General & Physical Tests
ASTM B117 Salt Spray (Fog) Corrosive Test
Salt spray tester is used to verify the anti-corrosion characteristics of all the materials surfaces of painting, coating, electroplating in condition of salt spray environment. Techtrivial salt spray test chamber meets ASTM, ISO, IEC and other International Standards test methods, capacity available in 108L, 320L, 410L, 780L, 1000L, 1600L capacity.
This highly competitive and reliable machine comes with:
- Temperature control and display unit
- Salt fog measure and control
- Continuous / periodic salt spraying
- Transparent lid to observe samples
- Standard sample holders
- Casters and holders are standard
- Hydrostatic hood seal
- Standard and custom.
- CE mark
SKU: n/a -
General & Physical Tests
Cold Bend Test | Cold Impact Test
IEC 60811-504 describes the cold bend test method for cables under low temperatures. The cold bend test on cable is only possible upto a maximum diameter of 12.5mm. The test is mainly conclusive to understand the flexibility and strength of plastic used over cable under low temperatures.
Whereas cold impact test on cables is performed according to IEC 60811-506. This test is mainly designed to simulate the plastic’s capacity to resist mechanical shock under cold environment.Here from a certain height, mandrels of specific weight are dropped on the cable.
SKU: n/a -
General & Physical Tests
Cold Elongation Testing Machine as per BS EN 60811-505 & IEC 60811-505
Cold Elongation test as per BS EN 60811-505 or IEC 60811-505from Tech trivial is a machine all fit inside with automatic elongation apparatus fit inside the cold chamber. The operator easily prepare sample and fix it before test is started and without opening the door thanks to HMI display and controller. High Quality loadcell and software is also provided with the equipment to make reporting easier and accurate with high precision.
Software Features:
- Full Machine Control, Start/Stop Elongation, Home Position
- Pre-programmable Sample Test Types removing the hassle of entering Sample Details and Type every time
- Display of Load Applied, Displacement and Temperature
- Speed Control to vary speed as per test requirement
- Simultaneous LIVE graph visibility (Load v/s Displacement) (Stress v/s Strain)
- Selectable Report formats to suit every client and test specific needs
- Tabular Data for Test with Graph recording for in-view software
SKU: n/a -
General & Physical Tests
Constant Temperature Water Bath
300L Constant Temperature Water Bath
A 300 liter constant temperature water bath is a specialized piece of equipment used for the testing of insulation resistance and withstand voltage of electric wires in water. The water bath is designed to maintain a constant temperature throughout the test, ensuring that the results are accurate and consistent.
The 300 liter water bath is typically used in the electric wire and cable industry to test the insulation properties of wires and cables. The test specimen, in this case, the electric wire, is submerged in the water bath, and a high voltage is applied to the wire to measure the insulation resistance and withstand voltage.
The water bath is equipped with a temperature controller that allows the operator to set and maintain the desired test temperature. The temperature range of the water bath can be adjusted according to the specific test requirements, typically between 20-90°C.
The water bath also includes a safety system that includes over-temperature protection, leakage protection, and earth leakage protection. These safety measures ensure the safety of the operators and the equipment during the test.
The 300 liter constant temperature water bath is a reliable and efficient tool for testing the insulation resistance and withstand voltage of electric wires in water. The constant temperature control and safety measures ensure accurate and consistent test results, making it an essential tool for quality control and product development in the electric wire and cable industry.
. It is in line with IEC60811-1-3 and UL1581-2006.
SKU: n/a -
General & Physical Tests
Copper Purity Test Apparatus
Copper Purity Test Apparatus is used to test the purity or percentage of Copper in a sample. The test itself is very important when it comes to determining conductor resistivity and conductivity. Many cases had have been seen when a micron of CU more has costed companies in millions for years. And many companies are though working upon copper optimization projects still they miss the lass mile of fine-tuning the process and product and 6 sigma level. All because the CU is not as pure as you are considering in your theoretical calculations. For more support you might get in touch with us on the topic, we provide free consultation on CU optimization projects.
SKU: n/a -
General & Physical Tests
Horizontal Cold Chamber up to -86 deg
Techtrivial designs and develop many ranges of cold chambers for cable and plastic compounding industry. Our range goes from -23 Degree Celsius to -86 degree Celsius where you can test not only servo cables with -15 degree Celsius operating temperature but also Arctic grade cables up to -86 degree Celsius.
SKU: n/a -
General & Physical Tests
Hot Air Bath (Underground, Above Ground all Size Possible)
• The gap between the walls is filled up with special grade glass wool for proper
insulation to avoid heat losses.
• Temperature Control, Thermostat (Temperature accuracy +/- 3 Deg C)
• On/Off Control (Temperature accuracy +/- 2 Deg C)
• PID Control (Temperature accuracy +/- 1 Deg C)
• Microprocessor control (Temperature accuracy +/- 0.5 Deg C
• Please specify the kind of controller and accuracy required at the time of
ordering.
• Water Circulation
• Water circulation using separate motor or stirrer.
• Elements
• Heating elements are made of high quality heaters which are put inside the
water bath and placed at the bottom of the bathSKU: n/a -
General & Physical Tests
Hot Air Oven (With or without Air change)
Our Ovens are sturdy, with double walled construction. Inner chamber made of
ALUMINIUM or STAINLESS-STEEL sheet. Outer chamber is made of stainless steel
or galvanized steel or mild steel sheet and are duly powder coated.
The gap between the walls is filled up with special grade glass wool for proper
insulation to avoid heat losses. Inner chamber has ribs for placing the shelves at
convenient levels. Supplied with 2 or 3 removable shelves. The oven door is mounted
on heavy hinges with a handle. Door is duly insulated .
Temp control uses Thermostat ,On/Off Control ,PID Control ,Microprocessor control
*Please specify the kind of controller and accuracy required at the time of ordering.SKU: n/a -
General & Physical Tests
Hot Pressure Deformation Test Tool as per IEC 60811-508
Hot deformation test is also called a hot pressure test is an acceptance test in order to assess high-temperature resistance of the material to deformation. Thermoplastics tend to deform under high temperatures and small damage during movement or under installation to cable, can cause a puncture or cut of insulation. This could result in the circuit break down shutting down the entire system.
According to the famous test institute of Germany, it was said that the most failing test for HO5-HO7V K cables is this test. In order to achieve a high speed of extrusion, manufacturers tend to inadvertently ignore the impact of compound degradation.SKU: n/a -
-
Electrical & Electronic, General & Physical Tests, Reaction to Fire Testing
IEC 60331-21 Resistance to Fire Alone – Fire Resistant Cable Test
Electrical & Electronic, General & Physical Tests, Reaction to Fire TestingIEC 60331-21 Resistance to Fire Alone – Fire Resistant Cable Test
Resistance To Fire Alone:
This is fire resistance test alone. In this test cable sample under test is held by means of suitable clamps. Five rings are provided for smaller diameter cables.SKU: n/a -
Automated Testing, General & Physical Tests, Machinery
IEC 60811 Wire or Cable Low Temperature Elongation Test Machine
Automated Testing, General & Physical Tests, MachineryIEC 60811 Wire or Cable Low Temperature Elongation Test Machine
Wire or Cable Low Temperature Elongation Test Machine is used for tensile testing of polymer materials, wire and cable, rubber, plastic and other insulating sheaths in low temperature environment. It is in line with GB/T2951.14-2008, Articles 8.3 and 8.4, VDE 0472Part616, IEC 60811- 1-4 and other test standards.
SKU: n/a -
General & Physical Tests
Low & Ultra-Low Temp Cold Chamber Machine (for -0 to -86 C )
- Cold Chamber Size (as per requirement of customer)
- Digital Temperature Indicating controller
- Glass Window on the door. (if required)
- Very high displacement compressor of about 22 per revolution
- Highly efficient refrigerant R404A having a boiling pt. Of -46DegC
- Our freezer does not require a low ambient temp. It can work even at an ambient of 40DegC
- Feed evaporator to improve the refrigeration effect and coeff. Of performance of the system as a whole
- High density PUF of about 60kg/cm3 so as to hold the temperature for a longer time
- Hot discharge is circulated on the mouth of the freezer to prevent cooling losses
- Microprocessor based temperature controller for accurate temperature and longer compressor life.
- Standard compressor of 1 hp with Cascading Refrigeration System
- Copper Capillary of higher wall thickness to last longer
- Uniform capillary distribution on the surface of chamber for faster and uniform cooling within chamber.
- Double door formation (acrylic + normal) for better insulation
- Noise less operations
SKU: n/a -
General & Physical Tests
Multi Cell Ageing Oven (IEC & UL2556 Compliant)
Multicell Ageing Ovens (with or Without HMI-PLC control)
Each Cell is a complete instrument in itself i.e., fitted with individual Temp. Indicating Controller, Air Flow Meter, Air temperature controller and an
Hour Meter. This enables the user to test different type of samples at desired temperature and duration, depending upon test requirement of end users
& testing authorities.
The instrument consists of the following:
• Double walled chamber with inside chamber of thick aluminum sheet. Size of the chamber is 10 cm x 30 cm
• Digital Temp. Indicating Controller with sensor. Temp. range 0-200 ± 2 o C
• Digital Flow meter for monitoring the volume of air passing through the chamber.
• Air inlet nozzle for the airline or air compressor.
• Specially Designed heaters to heat the air before it enters the cell
• Separate temperature controllers for air temperature control
• Air turbulence fan with motor to rotate at 60 RPM (Air source has to be provided by User)
• Specially designed cover to hold three to five test samples in each chamber.
• Timer System to record the total time of test.SKU: n/a -
General & Physical Tests, Machinery, Tools & Cable Components
Multi Die – Hydraulic Press Machine for Making Sample Molds
General & Physical Tests, Machinery, Tools & Cable ComponentsMulti Die – Hydraulic Press Machine for Making Sample Molds
A hydraulic press is a multi-use device as it can be used to mold the plastic samples for several testing requirements as well as day to day inspection such as Color matching tabs can be made with it, Limiting oxygen index test samples as per ISO 4589 can be prepared. The use of it is quite simple, but the granules on the dies of expected shape and press it on prescribed temperature, and within some minutes you get your sample as required.
SKU: n/a -
General & Physical Tests
Natural Gas Safety Valve (Socket)
Natural gas safety valve with a thermal device and quick connection. Available with a steel safety device (resistant up to 925 degrees), and with the brass safety device (resistant up to 650 degrees).
Also available without a thermal safety device.
SKU: n/a -
Automated Testing, General & Physical Tests, Machinery
Optical Profile Projector for cable
We have all range of Profile projectors suitable for cable and automotive manufacturing sector. Market is flooded with inaccurate and camera based profile projectors that are actually not compliant with Vision systems but still expansive as them.
Automatic profile projector for cable used in Cable Dimension measurement of any shape of the cable. Available with Accredited calibration master, color measurement, from 36 mm to 108 mm diameter samples.IEC-60502-1 and EN 50525 describes the requirement of exact dimension measurement of the insulation, inner jacket and outer jacket of a cable and it’s core.
Where you actually lose money?
- Having higher Insulation wall thickness due to the operator’s running safety margin
- Ovality of extrusion head setting causes the inhomogeneous spread of compound over the conductor.
- Due to higher core diameter, each next process of cable manufacturing such as stranding, taping, braiding, armoring, shielding, inner sheathing, outer jacketing takes a minimum of 0.05% to 3% of extra material.
- An average-sized Cable manufacturer who consumes 10 Million euros of plastics per year losses around 300.000 € just because of non-optimized dimension of cables.
We also supply all the measuring components calibrated by NABL accredited master instruments so that accuracy and uncertainty are never a concern for our clients.
SKU: n/a -
General & Physical Tests, Reaction to Fire Testing
Oxygen Index Test Apparatus of PVC & LSZH Compound as per ASTM D2863
General & Physical Tests, Reaction to Fire TestingOxygen Index Test Apparatus of PVC & LSZH Compound as per ASTM D2863
Limiting Oxygen Index & temperature index test as per IEC 60332, ASTM D2863, BS ISO 4589-2, NES 714. This test is directly connected to Cable manufacturing cost and for more info ask for a free consultation from us.
SKU: n/a -
General & Physical Tests
Shore A and D – Hardness Tester
The hardness tester is used for understanding the suitability of plastic compound material such as PVC, LSZH, EVA, PE, etc.
The test itself becomes very important when it is crucial to decide the temperature profile and tensile strength required for the product in the design phase. The hardness of the compound also determines flexibility of cable up to some extent.
SKU: n/a -
General & Physical Tests, Reaction to Fire Testing
Smoke Density Tester 61034
Smoke density test as per IEC 61034-1 and 2 is one of the most required test in the market for PVC and LSZH insulated/extruded cables.
The ROI of the instrument can be achieved with 1 year considering 3 tests per month.
SKU: n/a
