Reaction to Fire Testing
Go to Daily Deals SectionFire Survival & Smoke density testing apparatus
Fire Survival Test instrument:-
This instrument is designed to testing cables for resistance to fire of cable required to maintain circuit integrity under fire conditions. The instrument is
applicable to cables of rated voltage not exceeding 600/1000 V and of overall diameter less than or equal to 20mm (as per BS 6387) and diameter
exceeding 20mm (as per BS 7846).
The instrument is designed
Test cables under three protocols as per BS 6387:2013, BS 7846:2009 and BS 8491:2008 for
Protocol C: subject the cable under test to a flame via direct impingement corresponding to a temperature attach of 950 o C
Protocol W: subject the cable under test to a flame via direct impingement corresponding to a temperature attach of 650 o C with direct application of water
simulating a sprinkler system.
Protocol Z: subject the cable under test to a flame via direct impingement corresponding to a temperature attach of 950 o C with indirect application of
mechanical shock.
Smoke Density Test Chamber and associated photo system with Software:-
The instrument is manufactured as per the IEC specification and also confirms various other international standards. The instrument comprising of
• A Single walled 3m x 3m 3 m Chamber (powder Coated for long life).
• The Chamber is constructed on Aluminum Columns and 2mm thick GI Sheets. This ensure no rust formation on the chamber
• Door to access the chamber from inside with glass window, Alcohol Tray as per specifications, Sample Stand & Mixing fan inside the chamber along with
Sheet shielding as per specifications
• Constant DC power supply to produce 12 V DC, Light source and photometric System as per IEC 61034-1.
• Electronic Photometric System to capture and display the % Transmission of light, with specially developed software.
• Specially developed Software to capture % transmission from the photometric system.
• A computer (Windows 10) with preloaded software for interface and automatic reporting.
Flammability Test For Cables ( IEC 332 Pt 3 , BS EB 60332-3-10)
Cable fire testing equipment as per IEC 60332-3, instrument consists of (On request CPR compliant is also available)
Halogen Gas Emission Test Apparatus as per IEC-60754
UV Test Chamber as per ASTM G 153 & ASTM G 154 /ISO 4892-3
• A Programmed Timer automatically controls the UV & Condensation cycles of the UVCON &
programming.
• Temperature is measured & controlled by a solid state circuit. A PT-100 Sensor is
mounted in a black aluminum panel on the specimen rack.
• The temperature is set by the Operator & monitored by Digital panel meter on the
Control Panel. Note:- This version is with UV lamps but Xenon Arc (ISO 4892-2) is also
available on request.
The instrument Generally comprises:-
• A Double Walled Chamber for sample burning with front glass door
• A Burner settable 0- 90 o angle and precise gas control system including gas regulator
• Microprocessor control Burner Moving system
• Sample Holding System (adjustable both vertically and horizontally)
• Digital Timer for flame application (can be preset for 1 to 99 sec)
• Digital timer for flame observation after flame is removed.
Smoke Density Tester 61034
Smoke density test as per IEC 61034-1 and 2 is one of the most required test in the market for PVC and LSZH insulated/extruded cables.
The ROI of the instrument can be achieved with 1 year considering 3 tests per month.
Oxygen Index Test Apparatus of PVC & LSZH Compound as per ASTM D2863
Oxygen Index Test Apparatus of PVC & LSZH Compound as per ASTM D2863
Limiting Oxygen Index & temperature index test as per IEC 60332, ASTM D2863, BS ISO 4589-2, NES 714. This test is directly connected to Cable manufacturing cost and for more info ask for a free consultation from us.
Fire Survival & Circuit Integrity Test as per BS 6387 with CWZ
Fire survival & circuit integrity test as per BS 6387-CWZ is a state of art machinery for Cable manufacturers. Having it inhouse enables a manufacturer to test the prototypes as well as existing products on their own rather than paying 3000-6000 Euros to external laboratories each time. The Return of investment is super low in such cases.
Material Smoke Toxicity Hazard Classification Tester | Smoke Density Tester
The Simple Step by Step Classifying a Hazard Determine Process to chemical is hazardous based on its physical hazards, health hazards, and environmental hazards. Test your if the chemicals or consult determine how the above information scientific evidence to classifies the material.
Fire Resistance Tester | Fire Resistance Testing Machine ISO 834
What is ISO 834 Fire Resistance Tester of Building Materials and Elements?
It specifies a structural steel method for testing applied to members used fire protection systems in buildings as beams, columns, or tension members.
Automated Testing
Go to Daily Deals SectionAir Pressure Gauge or IAP AGC Air Gauge V4 Series
Colour Assessment Cabinet | Color Inspection/Matching Cabinet
The Cabinet is made out of Powder Coated M.S. Sheet, with inside Color as neutral grey & Outside Metallic Color.
There are different types of lights so that you can match with different requirements. All tube lights are operated separately by an electronic ballast. 450 Angle Plate is supplied for Viewing Samples. Hour Meter is used for totalizing the time for D-65 Tube Lights.
The design is user-friendly & easy maintenance.
Optical Profile Projector for cable
We have all range of Profile projectors suitable for cable and automotive manufacturing sector. Market is flooded with inaccurate and camera based profile projectors that are actually not compliant with Vision systems but still expansive as them.
Automatic profile projector for cable used in Cable Dimension measurement of any shape of the cable. Available with Accredited calibration master, color measurement, from 36 mm to 108 mm diameter samples.
IEC-60502-1 and EN 50525 describes the requirement of exact dimension measurement of the insulation, inner jacket and outer jacket of a cable and it’s core.
Where you actually lose money?
We also supply all the measuring components calibrated by NABL accredited master instruments so that accuracy and uncertainty are never a concern for our clients.
UV weathering test chamber as per ISO 4892 – XENON ARC
UV weathering test chamber as per ISO 4892 – XENON ARC
UV weathering test chamber as per ISO 4892-XENON ARC TEST EQUIPMENT generally compliant with HD 626-2 or ISO 4892-2
The test equipment consists of
please also check our Fluoroscent Lamp UV weathering test equipment for cost-effective version.
Xenon Arc Test or UV Weathering Test as per ISO 4892-2 & 3
Universal Tensile Strength Testing Machine for Plastics
Universal tensile test machine are largely used as cable and plastic test equipment. The tester can complete one test with a simple five-step operation: select the existing test method, input the sample size, install the sample, start the test, and print the report. There two models with different variants of force as per the requirements of customers.
IEC 60811 Wire or Cable Low Temperature Elongation Test Machine
IEC 60811 Wire or Cable Low Temperature Elongation Test Machine
Wire or Cable Low Temperature Elongation Test Machine is used for tensile testing of polymer materials, wire and cable, rubber, plastic and other insulating sheaths in low temperature environment. It is in line with GB/T2951.14-2008, Articles 8.3 and 8.4, VDE 0472Part616, IEC 60811- 1-4 and other test standards.
Electrical & Electronic
Go to Daily Deals SectionDC & AC High Voltage Tester / Current Tester
All types of AC-DC-Merged High Voltage/Current testers as per requirements and range of KVA:-
The DC/AC High Voltage tester provides ideal condition to test any cable for its capability to withstand high DC voltage
The Instrument consist of
Cable Fault Detector Machine TDR
Cable fault Location system (various technology)
The Cable Fault Locating System COMPAC 32 is used to perform DC high pot test, Pre-location of fault distance with the help of pre-locator unit and
Pin-point underground cable fault in acoustic method with the help of suitable Surge wave receiver and Pin-point sheath faults in power transmission and
distribution networks or service provider companies. Key features Operating Mode Surge, Arc / SIM, DC / Proof Test/ Pre-location and Sheath Fault
Pin-point location of cable faults in Low, Medium and High voltage cables by acoustic method.
Perform DC / Proof test up to 32 kV
DC Test Current 10/20mA
Burn test up to 32 kV – 60mA for short period
Surge Output voltage selectable in three ranges 8, 16 and 32 kV continuously variable
Full energy delivering capacity at each select range.
High Surge energy of 1000 Joules (optional 2000J)
Single Impulse and 1.5, 3 and 6 seconds intervals or as per customer request
Pre-location of cable faults distance with TDR, ICM, SIM/MIM & Decay mode.
Big LCD touchscreen color display.
Maximum measuring pre-location range up to 64km
Sheath fault location up to 8kV – 60mA
Protection Class – IP 54
LCR Measuring Instrument / Digital LCR Meter for Measuring
Basic Accuracy: 0.3 %
Measuring Rate: 3 meas / sec
Correction Function: Open / Short multi – frequency Zeroing
Display Mode: Direct, D %, D ABS
Display: 20 ́ 2 Characters LCD with Back – light
Operation Temperature and Humidity: 0°C 40°C, £ 90%RH
Power Requirements Voltage:
Ultrasonic Distance Meter for Distance Measurement
With up to 15 meters range and high precision our Ultrasonic handheld distance measurement system is a key to productivity. When the area of work and measurement to be performed are too tight to maneuver this handheld laser class 2 meter can indeed a be friend.
Coating Thickness Gauge
A digital coating thickness gauge (also brought up as a paint meter) is employed to live dry film thickness. Dry film thickness is maybe the foremost critical measurement within the coatings industry thanks to its impact on the coating process, quality and price. Dry film thickness measurements is accustomed evaluate a coating’s expected life, the product’s appearance and performance, and ensure compliance with a bunch of International Standards.
Digital Ultrasonic Thickness Gauge KM 8041
A coating thickness gauge (also brought up as a paint meter) is employed to live dry film thickness. Dry film thickness is maybe the foremost critical measurement within the coatings industry thanks to its impact on the coating process, quality and price. Dry film thickness measurements is accustomed evaluate a coating’s expected life, the product’s appearance and performance, and ensure compliance with a bunch of International Standards.
AC Current Clamp Adapter Meter CA300
This is AC Current Clamp Adapter Meter CA300 which is made by utilizing optimum quality raw material and the latest technology. In line with industry-standard, we provide the entire range in various customized options and at affordable prices.
True RMS Digital Insulation Multimeter
True RMS Digital Insulation Multimeter is a true RMS device (RMS means root mean square) is tool which can measure alternating current (ac) or ac voltage. Also it is used to check electrical circuits for faults.
True RMS Digital Insulation Multimeter is much more accurate than RMS when measuring AC Current.
Digit Large Display Digital Clamp Multimeter With Terminal Locking System
These are Digital Multimeter with 3 ½ Digit Large Display and with terminal locking System.
Looking for Digital Clamp Multimeter? Read more about the features of Digital Clamp Multimeter & make an informed choice to buy at the best price online.
True RMS Multi Parameter Mobile Logger Digital Multimeter KM 525 | Multimeter True RMS
True RMS Multi Parameter Mobile Logger Digital Multimeter KM 525 | Multimeter True RMS
These are True RMS Multi Parameter Mobile Logger Digital Multimeter with 4 digit display. It has 17 functions and 69 Ranges. It has 2 year of warranty and Dc voltage accuracy of 0.08%. Also it has 9 Volt Battery.
Tools & Cable Components
Go to Daily Deals SectionTip and Die
Cable Extrusion tip and dies in Italy from us are designed to your specification as per the requirement, with the lowest MOQ and frequency of order. Ask for free samples anytime.
DESCRIPTION (MATERIAL: HASTEALLOY) |
COMPRESSION TIPS |
SEMI-COMPRESSION TIPS |
TUBING TIPS |
EXTRUSION DIES |
DESCRIPTION (MATERIAL: SS440C) |
COMPRESSION TIPS with TC (Tungsten Carbide) insert |
SEMI-COMPRESSION TIPS |
TUBING TIPS |
EXTRUSION DIES |
Multi Die – Hydraulic Press Machine for Making Sample Molds
Multi Die – Hydraulic Press Machine for Making Sample Molds
A hydraulic press is a multi-use device as it can be used to mold the plastic samples for several testing requirements as well as day to day inspection such as Color matching tabs can be made with it, Limiting oxygen index test samples as per ISO 4589 can be prepared. The use of it is quite simple, but the granules on the dies of expected shape and press it on prescribed temperature, and within some minutes you get your sample as required.
